REDBACK (Wizard wing)



REDBACK
  Min weight Max weight
Vne Knots (IAS) 54 (62 mph) 54 (62 mph)
Manoeuvring speed Knots (IAS) 54 (62 mph) 54 (62 mph)
Trim Speed (middle hole) Knts (IAS) 30-36 (35-41 mph) 30-36 (35-41 mph)
Stall Speed Power Off knots (IAS) 23 (27 mph) 28 (33 mph)
Take Off Safety Speed knots (IAS) 31 (36 mph) 37 (43 mph)
Nominated approach speed knots (IAS) 31 (35 mph) 37 (43 mph)
Maximum Level Speed knots (IAS) 50 (57 mph) 50 (57 mph)
Cross winds of up to knots 11 (12 mph) 14 (16 mph)
Climb Rate at take off safety speed fpm   430
Cruising Speed Fwd CG knots (IAS) 40 (46 mph) 45 (52 mph)
Sink Rate at cruising speed fpm   450
Sink Rate at Vne fpm   904
Glide Ratio (engine off) 10:1 10:1
Take Off Distance (See Note 1) 240 metres (787 feet)
Landing Distance (See Note 1) 210 metres (689 feet)
Min airstrip length metres 310 metres (1017 feet)
Max wind operating conditions (at ground Level) knots 20 (23 mph) 20 (23 mph)
Rigging time Base 5 minutes Wing 15 minutes
Wing weight 45 kgs (99 lbs)
Trike empty weight from 118 kg (260 lbs)
Aircraft total empty weight from   165 kg (363.7 lbs)(see note 1)
Max. take off weight 401 kg (884 lbs)
Wing span   9.96 metres
Wing area   17.6 sq metres
Aspect ratio   5.6:1
Nose angle   121 degrees
No. of seats 2
Fuel tank capacity 44 litre (11.62 gallons)

Notes 1 The weights shown are approximate and can vary according to the equipment fitted to the aircraft.
Take off distances are performed as is required by the standard, where the distance is measured once the aircraft reaches an altitude of 50 feet.
